Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable

FOB Reference Price:Get Latest Price
$0.10 - $3.60 / Meters | 500 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China
Brand Name:
Huadong control cable.
Model Number:
flexible control cable
Application:
Industrial
Conductor Material:
Copper
Jacket:
PVC
Insulation Material:
PVC
color:
green&yellow blue brown black grey
core:
2 3 4 5 cores
sectionla area:
0.75 mm2 - 10 mm2
application:
for the data control
Item name:
flexible control cable
sample:
free
voltage:
450/750V
Supply Ability
Supply Ability:
8500000 Meter/Meters per Month Flexible Control Cable
Packaging & Delivery
Packaging Details
Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable packged in : length:100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.
Port
Qingdao/Tianjin/Shanghai/Ningbo/Guangzhou

Product Description

Item name: Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable


Cable Construction
  • Bare copper, fine wire conductors to DIN VDE 0295 cl. 5, BS 6360 cl. 5 and IEC 60228 cl. 5
  • Conductor insulation of halogen-free compound TI6, to E DIN VDE 0281 part 14
  • Color coded to DIN VDE 0293-308
  • Green-yellow grounding in the outer layer
  • Conductors stranded in layer with optimal lay-length
  • Halogen-free jacket compound TM7, to E DIN VDE 0281 part 14
  • Outer jacket color: Gray (RAL 7001)
  • LS0H = Low Smoke Zero Halogen-Free
Technical DataEuropean
  • Halogen-free flexible control cable, adapted to E DIN VDE 0281 part 14 and DIN VDE 0281 part 13
  • Temperature Range
    Flexing
    -15°C to +70°C (+5°F to +158°F)
    Fixed Installation
    -40°C to +70°C (-40°F to +158°F)
  • Nominal Voltage U0/U 450/750 V
  • Test Voltage 3000 V
  • Minimum Bending Radius
    Flexing approx. 12.5x cable Ø
    Fixed Installation approx. 4x cable Ø
  • Radiation Resistance
    Up to 100x106 cJ/kg (up to 100 Mrad)



Packaging & Shipping

Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable

1,100 to 1,000m reeled in carton drum or according to customers' requirement.
2) Outer packing: wooden case, carton box.
3) Other packing requirement according to client's request.

Our Services

Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable

1. We guarantee to offer new advanced goods.

2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction,installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing, If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.

3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.

4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.

Company Information

Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development,and domestic& international trade.

Established year: 1988

Total asset: USD 32 million

Plant area: 30000 m2

Number of staff: 380

Engineer:20

Laboratory Inspector: 18

Production line: 18

Testing machine:25

Producing capacity each year: 320000 km.

Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable  Standard:

Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on.

Meanwhile we can produce based on customers' requirements and specifications.

Halogen-Free Security Cable JB-750 HMH 450/750V fire and oil resistance Flexible Control Cable Certificate:

The company has passed ISO quality certification, CCC China Compulsory Certification, National Electrical

Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation

of Urban and Rural Power Grid Construction.

FAQ

1.what is our payment term ?

  Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

  The lead time usually is 10 - 30 working days.

3.what is the package of the cable ?

  The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

  Sure, we provide the free sample for customer to checking.
