bare conductor 477 mcm ACSR Hawk conductor price

FOB Reference Price:Get Latest Price
$0.50 - $10.00 / Meter | 1000 Meter/Meters acsr conductor (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China
Brand Name:
Huadong Cable
Model Number:
acsr Hawk conductor
Insulation Material:
bare
Type:
High Voltage
Application:
Overhead
Conductor Material:
Aluminum Alloy
Jacket:
Bare
material:
aluminum alloy
standard:
ASTM B-399-97
British standard:
BS 215
IEC Standard:
IEC 61089-91
Deutsches Standard:
DIN 48201
cross section:
150mm2
outer stranding:
right hand
packing:
standard export drum
application:
power distribution
advantage:
lower sag and higher corrosion resistance
Supply Ability
Supply Ability:
1000 Kilometer/Kilometers per Month acsr conductor
Packaging & Delivery
Packaging Details
bare conductor 477 mcm ACSR Hawk conductor price packging details is:
1. standard seaworthy drum (wooded rum,wooded steel drum, steel drum)
2. drum size can be customized or Meeting container the Max.load size
3. drum overall diameter can be from 1 meter to 2.2 meters
4. under customer requirement with certain length packed in rolls wraped in plastic tape or Nylon plastc tape
Port
Qingdao/Shanghai/Tianjin/Ningbo/Guangzhou
Lead Time :
Within 20 days to our port

bare conductor 477 mcm ACSR Hawk conductor price.

Product Description

Item name: bare conductor 477 mcm ACSR Hawk conductor price.



bare conductor 477 mcm ACSR Hawk conductor price Applications:

Used as bare overhead conductor for primary and secondary distribution. Designed utilizing a high strength aluminum alloy to achieve a high strength-to-weight ratio; affords better sag characteristics. Aluminum alloy gives AAAC higher resistance to corrosion than ACSR.



bare conductor 477 mcm ACSR Hawk conductor price Specifications:

AAAC bare conductor meets or exceeds the following ASTM specifications:
B-398 Aluminum Alloy 6201-T81 Wire for Electrical Purposes
B-399 Concentric-Lay-Stranded 6201 J81 Aluminum Alloy Conductors



bare conductor 477 mcm ACSR Hawk conductor price Construction:

Standard 6201-T81 high strength aluminum conductors, conforming to ASTM Specification B-399, are concentric-lay-stranded, similar in construction and appearance to 1350 grade aluminum conductors. Standard 6201 alloy conductors are similar to other alloy conductors commercially known as Ardival, Aldrey or Almelec. They were developed to fill the need for an economical conductor for overhead applications requiring higher strength than that obtainable with 1350 grade aluminum conductors, but without a steel core.

The DC resistance at 20"C of the 6201-T81 conductors and of the standard ACSR of the same diameter are approximately the same.
Conductors of the 6201 J81 alloys are harder and, therefore, have a greater resistance to abrasion than conductors of 1350-H 19 grade aluminum



Packaging & Shipping

bare conductor 477 mcm ACSR Hawk conductor price packging details is :
1. standard seaworthy drum (wooded rum,wooded steel drum, steel drum)
2. drum size can be customized or Meeting container the Max.load size

3. drum overall diameter can be from 1 meter to 2.2 meters
4. under customer requirement with certain length packed in rolls wraped in plastic tape or Nylon plastc tape

Our Services

bare conductor 477 mcm ACSR Hawk conductor price.

1. We guarantee to offer new advanced goods.

2. We'd like to send skilled personnel to the installing place to help offer technical consultant, quantity estimation and instruction, installing, preliminary testing,and help start up running; and to answer for any defect of the product found in installing and run testing, If there's something wrong with the product, we'll give our answer within 12 hours and get to the spot within 36 hours.

3.After installaton, We'll send skilled personnel to have the preliminary test and answer for any problems emerged. We take the whole charge of the fee needed in repairing,testing or retesting within the scope of our duty required in contract.

4.During the contract's period of validity,of the project must be started all over again or the goods can not be used at all which is resulted from our faulty goods and improper files or mistakes made by our instructors, we'll change the goods at once without compensation and take charge in all expenses of reinstallation.

Company Information

Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development,and domestic& international trade.

Established year: 1988

Total asset: USD 32 million

Plant area: 30000 m2

Number of staff: 380

Engineer:20

Laboratory Inspector: 18

Production line: 18

Testing machine:25

Producing capacity each year: 320000 km.



bare conductor 477 mcm ACSR Hawk conductor price Standard:

Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on. Meanwhile we  can produce based on customers' requirements and specifications.

bare conductor 477 mcm ACSR Hawk conductor price Certificates:

The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety  Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.

FAQ

1.what is our payment term ?

  Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

  The lead time usually is 10 - 30 working days.

3.what is the package of the cable ?

  The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

  Sure, we provide the free sample for customer to checking.
