50mm 70mm 95mm 120mm 150mm copper rubber Welding cable

FOB Reference Price:Get Latest Price
$0.15 - $39.00 / Meters | 200 Meter/Meters rubber cable (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China
Brand Name:
Huadong
Model Number:
rubber cable
Insulation Material:
Rubber
Type:
Low Voltage
Application:
Industrial
Conductor Material:
Copper
Jacket:
Rubber
sample:
free
stock:
in stock
OEM:
welcome
color:
black orange red
voltage:
AC 200V~DC 400V
Delivery:
by sea or according to customer's requirment.
Provider:
Directly factory
Standard:
IEC 60245
item name:
rubber cable
material:
copper aluminum
Supply Ability
Supply Ability:
150000 Kilometer/Kilometers per Month according to your order for Copper Rubber Welding Cable
Packaging & Delivery
Packaging Details
50mm 70mm 95mm 120mm 150mm copper rubber Welding cable
wooden drum, steel wooden drum , Iron wooden drum , also according to your requirment.
Port
Qingdao,Tianjin,Shanghai or others rubber cable
Lead Time :
Shipped in 7 days after payment



Product Description

50mm 70mm 95mm 120mm 150mm copper rubber Welding cable.

 Application:

         The cables are suitable for welding machine as secondary earth wire with secondary side to-ground volatage not more than 200V AC and impulse voltage peak 400V DC, or for connecting electrode holders.

Continuous operating temperature ≤60°C.

 Standard:

         IEC 60245, GB5013.6-1997ConductorFlexible Annealed Copper SheathNatural Rubber (Type YH)Neoprene Rubber or other equivalent Synthetic Rubber Elastomer (Type YHF)Temperature Rating0oC-65oCStock colors black & red (others available)

  Technical data & size



Nominal Section-Area of Conductor(mm2)Structure of ConductorNominal Thik-ness of Sheath  (mm)Overall  DiameterMax. Conductor Resistance at 20º C  (Ω /km)Approx. Weight (kg/km)
Core no. /Dia. (no. /mm)Min.Max.YHYHF
10322/0.201.87.59.71.91146153.51
16513/0.202.09.211.51.16218.9230.44
25798/0.202.010.513.00.758316.6331.15
351121/0.202.011.514.50.536426439.87
501596/0.202.213.517.00.379592.47610.55
702214/0.202.415.019.50.268790817.52
952997/0.202.617.022.00.1981066.171102.97
1201702/0.302.819.024.00.1611348.251392.55
1502135/0.303.021.027.00.1281648.51698.72
1851443/0.403.222.029.00.1061983.82020.74







Packaging & Shipping

50mm 70mm 95mm 120mm 150mm copper rubber Welding cable.
1) Packing length:100 to 1,000m reeled in carton drum or according to customers' requirement
2.By standard wooden drum or roll.
3.Drum size:1100mm*1100mm*1100mm or as your request .



Our Services

50mm 70mm 95mm 120mm 150mm copper rubber Welding cable.

Advanced connectors & assembly cables machines and testing equipments.
Large production capacity, short delivery.
Strict QC checking before delivery.
OEM/ODM service available, help you on designing.
Prompt quotation for your inquiry.
More than 10 years experiences in cable and wire field.
Professional connector and cable manufacturer, with good quality and competitive price.
free samples are available for further evaluation and you are highly welcome to visit our factory anytime!!

Company Information

Henan Huadong Cable Co., Ltd is a joint stock enterprise integrated incable production, research & development, and domestic& internationatrade.

Established year: 1988

Total asset: USD 32 million

Plant area: 30000 m2

Number of staff: 380

Engineer:20

Laboratory Inspector: 18

Production line: 18

Testing machine:25

Producing capacity each year: 320000 km



50mm 70mm 95mm 120mm 150mm copper rubber Welding cable Standard:

Our products are produced according to the standards of GB, IEC, BS, DIN, ASTM, JIS, NF, AS/NZS, CSA and so on. Meanwhile we can produce based on customers' requirements and specifications.

50mm 70mm 95mm 120mm 150mm copper rubber Welding cable Certificate:

The company has passed ISO90012008 quality certification, CCC China Compulsory Certification, National Electrical Product Safety Certification, State Construction and ProjectCommitee Recommended Manufacturer of the Transformation of Urban and Rural Power Grid Construction.

FAQ

1.what is our payment term ?

 Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight.

2.what is the lead time ?

The lead time usually is 10 - 30 working days.

3.what is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirment.

4.Could we provide the free sample for customer ?

Sure, we provide the free sample for customer to checking.
